Yuchai
Open Type Genset
Contact us to get price information for this product.
Guangxi Yuchai Machinery Co.Ltd .(NYSE:CYD)is the core subsidiary of Guangxi Yuchai Machinery Group Co.,Ltd.,with over 9,000 employees,total assets of over 16 billion yuan and an annual engine output of 700,000units.We completed the shareholding reform in 1992,became a Chinese -foreign joint venture in 1993 through restructuring ,and went public on the New York Stock Exchange in 1994 as China’s first engine manufacturer listed abroad.Headquartered in Yulin,Guangxi ,we have 7 subsidiaries and production bases in areas such as Fujian ,Jiangsu, Anhui and Shandong.
Detail
| Basic Characteristics of Cummins Serials Diesel Generator Set | |
| engine | ◆All series powered by the Cummins engine, modern technique, dependable performance，high combustion efficiency and low fuel consumption, long time continuous running, long working life, and Easy to maintain. Conform to the standard of IS03046. |
| Alternator | ◆All series adopt alternator of Stamford / Marathon/ Faraday/Engga; Excellent excitation characteristics, Ensure that the genset can withstand high power load moment, small Voltage fluctuation, quickly recover. Conform to the standard of GB755，BS5000，IEC34-1,CSA22.2,AS2359. |
| Controller System | ◆All series use automatic Powertec GC6110 as controller, Integrating digital, intelligent, network technology,use for a single diesel generator set automation and monitoring system,implement a automatic starting/stopping ,the data measured, Alarm protection function of the genset. |
| Radiator | ◆Standard 50℃ ambient temperature online radiator, Closed water circulation cooling system, ensure the rated power output of under high temperature environment. |
| Steel Welding Base shock absorber | ◆Inbuilt shock absorber, perfect shock absorption performance, Easy installation and transport |
| ◆No need to install shock pad on the connection of base foundation and fixed. | |
| Diesel Generator Set Performance Parameters | ||
| Diesel Generator Set Performance Parameters | ◆Frequency drop ≤3% | ◆Voltage modulation ≤0.3% |
| ◆Steady state frequency ≤0.5% | ◆Steady state voltage deviation ≤±1% | |
| ◆Transient frequency deviation ≤+10% ≤-7% | ◆Transient voltage deviation ≤+20% ≤-15% | |
| ◆Frequency recovery time ≤3S | ◆voltage recovery time ≤1S(Voltage±3%) | |
| ◆THF <3 | ||
| ◆TIF <50 Conform to the standard of NEMA MG1-22.43 | ||
| Standard Detection Function | ||
| Standard Detection Function | ◆3 phases voltage Ua,Ub,Uc | ◆3 phases current La,Lb,Lc |
| ◆Frequency F1 | ◆Active power PA | |
| ◆Apparent power PR | ◆Power factor PF | |
| ◆Coolant temperature WT | ◆℃ display | |
| ◆Oil pressure OP | ◆kPa/Psi/Bar display | |
| ◆Speed RPM | ◆Battery voltage :V | |
| ◆HC timer records 99999 hours | ◆The maximum cumulative times of starting can reach 999999 | |
| Supplied Accessories and Optional Items | ||
| Supplied Accessories | ◆Silencer、bellows、exhaust bend,Battery connect wire | |
| Optional Items | ◆Silent/trailer type genset | ◆Oil water separator |
| ◆Heat exchanger—water tower cooling system | ◆Low water level, low fuel oil warning function | |
| ◆Genset environmental protection | ◆Mains supply monitoring automatic control system | |
| ◆600L or 1000L Storage fuel tank | ◆BAC 06 battery charger | |
Download File
| No. | Genset Model | 50hz, 230v/400v, 1500rpm, 0.8 PF | Engine Type | Datasheet Download | |||
| Prime/KW | Standby/KW | Prime/Kva | Standby/Kva | ||||
| 1 | PYC45A | 35 | 30 | 44 | 38 | YC4D60-D21 | PYC40A-YC4D60-D21.pdf |
| 2 | PYC75A | 60 | 50 | 75 | 63 | YC4D90Z-D21 | PYC75A-YC4D90Z-D21.pdf |
| 3 | PYC85A | 65 | 60 | 81 | 75 | YC4A100Z-D20 | PYC85A-YC4A100Z-D20.pdf |
| 4 | PYC115A | 90 | 80 | 113 | 100 | YC4A140L-D20 | PYC115A-YC4A140L-D20.pdf |
| 5 | PYC150A | 120 | 100 | 150 | 125 | YC4A180L-D20 | PYC150A-YC4A180L-D20.pdf |
| 6 | PYC150A | 120 | 100 | 150 | 125 | YC6B180L-D20 | PYC150A-YC6B180L-D20.pdf |
| 7 | PYC165A | 130 | 120 | 163 | 150 | YC6B205L-D20 | PYC165A-YC6B205L-D20.pdf |
| 8 | PYC200A | 160 | 150 | 200 | 188 | YC6A245L-D21 | PYC200A-YC6A245L-D21.pdf |
| 9 | PYC275B | 220 | 200 | 275 | 250 | YC6MK350L-D20 | PYC275B-YC6MK350L-D20.pdf |
| 10 | PYC350B | 280 | 250 | 350 | 313 | YC6MK420L-D20 | PYC350B-YC6MK420L-D20.pdf |
| 11 | PYC375B | 300 | 280 | 375 | 350 | YC6MJ480L-D20 | PYC375B-YC6MJ480L-D20.pdf |
| 12 | PYC415B | 330 | 300 | 413 | 375 | YC6MJ500L-D21 | PYC415B-YC6MJ500L-D21.pdf |
| 13 | PYC440B | 350 | 320 | 438 | 400 | YC6T550L-D21 | PYC440B-YC6T550L-D21.pdf |
| 14 | PYC500B | 400 | 350 | 500 | 438 | YC6T600L-D22 | PYC500B-YC6T600L-D22.pdf |
| 15 | PYC550B | 440 | 400 | 550 | 500 | YC6T660L-D20 | PYC550B-YC6T660L-D20.pdf |
| 16 | PYC25A | 18 | 16 | 23 | 20 | 4D24G6 | PYC25A-4D24G6.pdf |
| 17 | PYC30A | 22 | 20 | 28 | 25 | 4D24G7 | PYC30A-4D24G7.pdf |
| 18 | PYC35A | 26 | 24 | 33 | 30 | 4D24TG2 | PYC35A-4D24TG2.pdf |
| 19 | PYC45A | 33 | 30 | 41 | 38 | 4D24TG0 | PYC45A-4D24TG0.pdf |
| 20 | PYC65A | 50 | 40 | 63 | 50 | YC4D80-D34 | PYC65A-YC4D80-D34.pdf |
| 21 | PYC70A | 55 | 50 | 69 | 63 | YC4D90-D34 | PYC70A-YC4D90-D34.pdf |
| 22 | PYC80A | 64 | 60 | 80 | 75 | YC4D105-D34 | PYC80A-YC4D105-D34.pdf |
| 23 | PYC100A | 80 | 70 | 100 | 88 | YC4D120-D31 | PYC100A-YC4D120-D31.pdf |
| 24 | PYC115A | 90 | 80 | 113 | 100 | YC4D140-D31 | PYC115A-YC4D140-D31.pdf |
| 25 | PYC125A | 100 | 90 | 125 | 113 | YC4D155-D31 | PYC125A-YC4D155-D31.pdf |
| 26 | PYC115A | 90 | 80 | 113 | 100 | YC4A140-D30 | PYC115A-YC4A140-D30.pdf |
| 27 | PYC125A | 100 | 90 | 125 | 113 | YC4A155-D30 | PYC125A-YC4A155-D30.pdf |
| 28 | PYC125A | 100 | 90 | 125 | 113 | YC4A165-D30 | PYC125A-YC4A165-D30.pdf |
| 29 | PYC150A | 120 | 110 | 150 | 138 | YC4A190-D30 | PYC150A-YC4A190-D30.pdf |
| 30 | PYC175A | 140 | 120 | 175 | 150 | YC6A205-D30 | PYC175A-YC6A205-D30.pdf |
| 31 | PYC190A | 150 | 140 | 188 | 175 | YC6A230-D30 | PYC190A-YC6A230-D30.pdf |
| 32 | PYC200A | 160 | 150 | 200 | 188 | YC6A245-D30 | PYC200A-YC6A245-D30.pdf |
| 33 | PYC225A | 180 | 160 | 225 | 200 | YC6A275-D30 | PYC225A-YC6A275-D30.pdf |
| 34 | PYC275B | 220 | 200 | 275 | 250 | YC6MK350-D30 | PYC275B-YC6MK350-D30.pdf |
| 35 | PYC350B | 280 | 250 | 350 | 313 | YC6MK420-D30 | PYC350B-YC6MK420-D30.pdf |
| 36 | PYC375B | 300 | 280 | 375 | 350 | YC6MK450-D30 | PYC375B-YC6MK450-D30.pdf |
| 37 | PYC415B | 330 | 300 | 413 | 375 | YC6MJ500-D30 | PYC415B-YC6MJ500-D30.pdf |
| 38 | PYC415B | 330 | 300 | 413 | 375 | YC6K500-D31 | PYC415B-YC6K500-D31.pdf |
| 39 | PYC415B | 330 | 300 | 413 | 375 | YC6K500-D30 | PYC415B-YC6K500-D30.pdf |
| 40 | PYC440B | 350 | 320 | 438 | 400 | YC6K520-D30 | PYC440B-YC6K520-D30.pdf |
| 41 | PYC500B | 400 | 350 | 500 | 438 | YC6K600-D30 | PYC500B-YC6K600-D30.pdf |
| 42 | PYC550B | 440 | 400 | 550 | 500 | YC6T660-D31 | PYC550B-YC6T660-D31.pdf |
| 43 | PYC625B | 500 | 450 | 625 | 563 | YC6TD780-D31 | PYC625B-YC6TD780-D31.pdf |
| 44 | PYC690B | 550 | 500 | 688 | 625 | YC6TD840-D31 | PYC690B-YC6TD840-D31.pdf |
| 45 | PYC750B | 600 | 550 | 750 | 688 | YC6TD900-D31 | PYC750B-YC6TD900-D31.pdf |
| 46 | PYC815B | 650 | 600 | 813 | 750 | YC6TD1000-D30 | PYC815B-YC6TD1000-D30.pdf |
| 47 | PYC825B | 660 | 600 | 825 | 750 | YC6C1020-D31 | PYC825B-YC6C1020-D31.pdf |
| 48 | PYC890B | 710 | 650 | 888 | 813 | YC6C1070-D31 | PYC890B-YC6C1070-D31.pdf |
| 49 | PYC1000B | 800 | 730 | 1000 | 913 | YC6C1220-D31 | PYC1000B-YC6C1220-D31.pdf |
| 50 | PYC1125B | 900 | 800 | 1125 | 1000 | YC6C1320-D31 | PYC1125B-YC6C1320-D31.pdf |
| 51 | PYC1250B | 1000 | 900 | 1250 | 1125 | YC6C1520-D31 | PYC1250B-YC6C1520-D31.pdf |
| 52 | PYC1375B | 1100 | 1000 | 1375 | 1250 | YC6C1660-D30 | PYC1375B-YC12VC1680-D31.pdf |
| 53 | PYC1100B | 880 | 800 | 1100 | 1000 | YC12VTD1350-D30 | PYC1100B-YC12VTD1350-D30.pdf |
| 54 | PYC1250B | 1000 | 900 | 1250 | 1125 | YC12VTD1500-D30 | PYC1250B-YC12VTD1500-D30.pdf |
| 55 | PYC1375B | 1100 | 1000 | 1375 | 1250 | YC12VTD1680-D30 | PYC1375B-YC12VTD1680-D30.pdf |
| 56 | PYC1500B | 1200 | 1100 | 1500 | 1375 | YC12VTD1830-D30 | PYC1500B-YC12VTD1830-D30.pdf |
| 57 | PYC1690B | 1350 | 1200 | 1688 | 1500 | YC12VTD2000-D30 | PYC1690B-YC12VTD2000-D30.pdf |
| 58 | PYC1375B | 1100 | 1000 | 1375 | 1250 | YC12VC1680-D31 | PYC1375B-YC12VC1680-D31.pdf |
| 59 | PYC1690B | 1350 | 1200 | 1688 | 1500 | YC12VC2070-D31 | PYC1690B-YC12VC2070-D31.pdf |
| 60 | PYC1875B | 1500 | 1350 | 1875 | 1688 | YC12VC2270-D31 | PYC1875B-YC12VC2270-D31.pdf |
| 61 | PYC2000B | 1600 | 1500 | 2000 | 1875 | YC12VC2510-D31 | PYC2000B-YC12VC2510-D31.pdf |
| 62 | PYC2250B | 1800 | 1700 | 2250 | 2125 | YC12VC2700-D31 | PYC2250B-YC12VC2700-D31.pdf |
| 63 | PYC2500B | 2000 | 1800 | 2500 | 2250 | YC16VC3000-D31 | PYC2500B-YC16VC3000-D31.pdf |
| 64 | PYC2750B | 2200 | 2000 | 2750 | 2500 | YC16VC3300-D31 | PYC2750B-YC16VC3300-D31.pdf |
| 65 | PYC3000B | 2400 | 2200 | 3000 | 2750 | YC16VC3600-D31 | PYC3000B-YC16VC3600-D31.pdf |
